Project Description

Drone Based 3D Reconstruction for Arch – Viz:

Photos taken with aDJI Phantom IV

Number of Photos Taken for Reconstruction: 180+ Pictures

This Project was for an Architect Office. We got out everything the Architect nedded to make his Project for the Site. Building Dimensions, Heights, Distance between them and so.

We took the Images with the DJI Phant IV Pro. It was a Straight Forward Process, i took us not more then 2 Days to do the whole Reconstruction.

For a Better Workflow we created a Low Poly Object to insert in the Architects CAD Program. Then, for the final Rendering, we Rendered out the High Poly Model with High Res Textures.

Later on we will try to Port this into Unity3D for Real Time Architectural Visualizations.


Overall Progress:
